Replace the 2230 SSD in Dell Pro Micro Plus QBM1250

Name: Replace the 2230 SSD in Dell Pro Micro Plus QBM1250
Uploaded: 2026-07-31T05:22:06-04:00
Duration: 1 min 8 s
Description: Dell Pro Micro Plus QBM1250 | How to replace the 2230 solid state drive in a dual SSD configuration IMPORTANT NOTE Always back up your data of your disk ( on cloud or external storage ) and consult your d bualefore trying to remove or to install any co...

Dell Technologies

07/31/2026

0 (0%)

Report Like Favorite

TL;DR

Power down the Dell Pro Micro Plus QBM1250 and disconnect all peripherals before beginning any internal component work to avoid damage or injury.
Remove the side cover by loosening its screws, then identify the 2230 SSD, remove its retaining screw, lift it out, and unlatch it from the carrier assembly.
Reinstallation is the reverse process: re-latch the drive to the assembly, seat it, tighten the screw, and replace the side cover securely.

Summary

This official Dell Technologies tutorial demonstrates how to remove and reinstall a 2230 form-factor solid state drive in the Dell Pro Micro Plus QBM1250 desktop in a dual SSD configuration. The process begins with essential safety precautions: reviewing the Owner's Manual, powering down the system, and disconnecting all peripherals before touching any internal components. The physical procedure covers loosening the side cover screws, lifting the cover away, identifying the target SSD, removing the retaining screw, lifting the drive out, and unlatching it from its carrier assembly. Reinstallation follows the reverse sequence — re-latching the drive to the assembly, seating it in the system, securing the screw, and replacing the side cover. A critical operational note is highlighted at the end: the system will only power on and exit service mode when the power adapter is connected. Viewers are directed to dell.com/support for the full Owner's Manual and additional system documentation.

Chapters

0:00 - Safety Precautions
0:17 - Preparing the System
0:23 - Removing the SSD
0:39 - Reinstalling the SSD

Key Quotes

0:00 "Be sure to read and follow the safety guidelines to protect your computer from potential damage and ensure your personal safety."
0:30 "Identify the solid state drive and loosen the screw."
0:54 "Please note, the system will only power on and exit service mode if the adapter is connected."

FAQ

What should I do before removing the SSD from the Dell Pro Micro Plus QBM1250?

Turn off the computer, disconnect all attached peripherals, and review the safety guidelines in the Owner's Manual at dell.com/support. Using proper ESD protection is also strongly recommended.

Why won't my QBM1250 power on after reassembly?

The system will only power on and exit service mode if the power adapter is connected. Ensure the adapter is plugged in before attempting to boot after completing the SSD replacement.
