Configure Asset Layout Mapping in Hudu Radar

Name: Configure Asset Layout Mapping in Hudu Radar
Uploaded: 2026-08-25T09:55:39-04:00
Duration: 3 min 43 s
Description: In part two of this series, learn how to configure asset mapping in Hudu Radar to automatically sync discovered devices into your documentation. We’ll show you how to map device types to asset layouts, connect fields to Radar data points, and set up au...

Hudu

08/25/2026

0 (0%)

Report Like Favorite

Transcript

Radar to bring assets into your environment, and we'll cover those in this video. The first step is to configure asset layout mapping, which you can do by going into Admin and into Hudu Radar. Once you've mapped an asset layout to a Radar device type, you'll be able to connect fields in that layout to Radar data points. As you can see here in my Radar settings, I have Workstations mapped to my Workstations asset layout, Switches to my Switches asset layout, and so on. If you didn't want to bring in a particular device type at all, let's say mobile devices, we would just leave this box blank. And if you wanted multiple device types to land in the same asset layout, let's say network devices, we could go ahead and specify that here. The other thing you'll need to do in this section is state your device requirements. Selecting these requirements essentially means that any device that doesn't meet all of them will not be sent to Hudu. If you have certain device requirements that are not set, but Radar still detects them, they will still populate as fields inside of Hudu. So now that we have the asset layout mapping done and the device requirements set, let's go ahead and jump into our asset layouts. Here we can see how the asset layouts actually connect to Hudu Radar. This asset layout is already set up and is in use for Hudu Radar, as you can see from this banner above. Right now, rich text and text fields are the only fields that can be used for Radar data points. Here in my IP address field, there is a sources section with a dropdown to select a Hudu Radar data point. I've selected IP address from that dropdown to tell Radar this is the field I want it to populate. A quick tip for you, most data points are going to be best served with the text field type, but data points that should use rich text such as CPUs, disks, and interfaces often come back as a bulleted list of values. One thing to keep in mind, if you make a Radar data point field required, the asset will only be created once Hudu Radar is able to complete that field. If Radar can't complete a required field, the asset won't be created and the device won't be sent to Hudu. Another way to leverage Hudu Radar is the ability to automatically create warranty expirations. Using my warranty expiration field here, I can select the date field type and check the box to automatically add it to the expirations list and to use Hudu Radar to create a warranty expiration if vendor and serial numbers are found for a device. That's everything you need to get your asset layouts created and set up to start syncing in Hudu Radar devices. As soon as you've done this, check out the next video in this Hudu Radar series where we'll cover managing the devices that Radar actually brings in. Thank you all so much for joining, if you do have any questions, feel free to reach out to us at support.hudu.com or leave a comment below.

TL;DR

Map Radar device types to asset layouts in Admin > Hudu Radar; leave a type unmapped to exclude it, or point multiple types to one layout.
Set device requirements to filter which discovered devices get forwarded to Hudu — devices that don't qualify are blocked before reaching documentation.
Connect individual asset layout fields to Radar data points via a sources dropdown; use text fields for most values and rich text for multi-value outputs like CPUs or interfaces.
Enable automatic warranty expiration creation by selecting the date field type and checking the Radar warranty option — triggers when vendor and serial number data are present.

Summary

This tutorial walks through the configuration steps required to connect Hudu Radar with your asset layouts so that discovered devices automatically sync into your Hudu documentation environment. The process begins in the Admin panel under Hudu Radar settings, where administrators map each Radar device type — such as Workstations, Switches, or Network Devices — to a corresponding asset layout. Device types that should be excluded, like mobile devices, are simply left unmapped, while multiple device types can be directed into a single shared layout when needed. Device requirements can also be set at this stage, ensuring only qualifying devices are forwarded to Hudu; devices that fail to meet requirements are filtered out before reaching documentation. From there, the video demonstrates how individual asset layout fields are connected to specific Radar data points using a sources dropdown. Text fields are recommended for most data points, while rich text fields are better suited for multi-value outputs like CPUs, disks, and network interfaces, which return as bulleted lists. Marking a Radar data point field as required means the asset will only be created once Radar can populate that field — if it cannot, the device is withheld entirely. Finally, the tutorial covers automatic warranty expiration creation: by selecting the date field type on a warranty expiration field and enabling the relevant checkbox, Hudu Radar will automatically generate warranty expiration records whenever vendor and serial number data are available for a device.

Chapters

0:00 - Introduction & Overview
0:13 - Asset Layout Mapping Setup
1:03 - Device Requirements Configuration
1:36 - Connecting Fields to Radar Data Points
2:50 - Automatic Warranty Expiration Setup

Key Quotes

1:09 "Selecting these requirements essentially means that any device that doesn't meet all of them will not be sent to Hudu."
2:13 "Most data points are going to be best served with the text field type, but data points that should use rich text such as CPUs, disks, and interfaces often come back as a bulleted list of values."
2:30 "If you make a Radar data point field required, the asset will only be created once Hudu Radar is able to complete that field."
2:50 "Another way to leverage Hudu Radar is the ability to automatically create warranty expirations."

FAQ

What happens if a device doesn't meet the requirements set in Hudu Radar?

Any device that fails to meet all configured device requirements will not be sent to Hudu. However, if certain requirements are not set and Radar still detects those attributes, they will still populate as fields inside Hudu.

Can I send multiple device types into the same asset layout?

Yes. In the Radar settings under Admin, you can map multiple device types — for example, different categories of network devices — to the same asset layout by specifying that layout for each applicable device type.
