Replace the 2230 SSD in Dell Pro Micro Plus QBM1250

Name: Replace the 2230 SSD in Dell Pro Micro Plus QBM1250
Uploaded: 2026-08-17T10:08:58-04:00
Duration: 1 min 8 s
Description: Dell Pro Micro Plus QBM1250 | How to replace the 2230 solid state drive in a single SSD configuration IMPORTANT NOTE Always back up your data of your disk ( on cloud or external storage ) and consult your manual before trying to remove or to install an...

Dell Technologies

08/17/2026

0 (0%)

Report Like Favorite

TL;DR

Power down the Dell Pro Micro Plus QBM1250 and disconnect all peripherals before beginning any SSD removal or installation work.
Remove the side cover by loosening its screws, then extract the M.2 2230 SSD by removing two retaining screws — one on each side of the drive.
Reinstallation is the reverse of removal; ensure all screws are tightened and the side cover is fully secured before reconnecting power.

Summary

This short official tutorial from Dell Technologies walks through the complete process of removing and reinstalling an M.2 2230 solid state drive in the Dell Pro Micro Plus QBM1250 desktop in a single-SSD configuration. The video begins with a safety reminder to consult the Owner's Manual at dell.com/support and to power down and disconnect all peripherals before beginning. The removal steps cover loosening the side cover screws, lifting the panel off, identifying the SSD, removing the retaining screw, extracting the drive, and detaching the secondary hardware screw. Reinstallation follows the reverse sequence — securing the drive with its screw, reseating it in the chassis, replacing the side cover, and tightening all fasteners. A key note at the end reminds users that the system will only power on and exit service mode when the power adapter is connected. This is a straightforward DIY customer-replaceable unit (CRU) procedure suitable for end users comfortable with basic hardware handling and proper ESD precautions.

Chapters

0:00 - Safety Guidelines & Prerequisites
0:17 - Powering Down the System
0:23 - Removing the 2230 SSD
0:39 - Reinstalling the 2230 SSD

Key Quotes

0:00 "Be sure to read and follow the safety guidelines to protect your computer from potential damage and ensure your personal safety."
0:23 "To remove the solid state drive 2230, loosen the screws securing the side cover and lift the cover off the system."
0:54 "Please note, the system will only power on and exit service mode if the adapter is connected."

FAQ

Do I need a technician to replace the SSD in the Dell Pro Micro Plus QBM1250?

No. Dell classifies this as a DIY Customer Replaceable Unit (CRU), meaning end users can perform the replacement themselves. Always follow the safety guidelines in the Owner's Manual and use proper ESD protection.

Why won't my QBM1250 power on after reassembly?

The system will only power on and exit service mode if the power adapter is connected. Ensure the adapter is plugged in before attempting to boot after completing the SSD replacement.
