Dell: How to Replace the 2230 SSD in Dell Pro 24 AIO

Dell Technologies
07/21/2026
0 (0%)
Share
  • Comments
  • Download
  • Transcript
Report Like Favorite
  • Share/Embed
  • Email
Link
Embed

Transcript


and ensure your personal safety. For more information about safety guidelines, see the Owner's Manual at dell.com slash support. Before you begin, turn off the computer and disconnect all the attached peripherals. To remove the solid state drive, 2230, unlatch the stand and lift it off the system. Unlatch and remove the back cover. Identify the system board shield and remove the six screws. Lift the shield out of the system. Identify the wireless module and remove the screw securing it. Unlatch and disconnect the cables to lift the module out of the system. Identify the I O cover and remove the two screws. Lift the cover out of the system. Identify the solid state drive and remove the screw. Lift the drive out of the system. To reinstall the solid state drive 2230, place it back in the system and secure it with the screw. Place the I O cover back on the system and tighten the two screws. Place the wireless module back in the system and reconnect the cables. Relatch it and install the screw to secure it. Place the system board shield back in the system and secure it with the six screws. Relatch the back cover to the system and then relatch the stand. For more information about your Dell system, visit Dell.com slash support.

TL;DR

  • Accessing the 2230 SSD in the Dell Pro 24 AIO requires removing the stand, back cover, system board shield, wireless module, and I/O cover before the drive is reachable.
  • The removal process involves a total of nine screws across multiple components; reinstallation follows the exact reverse order of disassembly.
  • Dell strongly recommends backing up all data and using ESD protection before beginning any internal hardware replacement or upgrade procedure.

Summary

This official Dell Technologies tutorial walks through the complete process of removing and reinstalling a 2230 M.2 solid state drive in the Dell Pro 24 All-in-One (AIO) desktop, model QC24251. The video covers every disassembly step required to access the SSD, including detaching the stand, removing the back cover, unscrewing the system board shield, disconnecting the wireless module, and lifting out the I/O cover before reaching the drive itself. Reinstallation follows the reverse sequence, with clear guidance on securing each component with the correct number of screws. Before beginning, viewers are reminded to back up all data, shut down and unplug the system, and use proper electrostatic discharge (ESD) protection to avoid component damage. The tutorial is designed for end users performing a DIY upgrade or replacement and references Dell's official Owner's Manual at dell.com/support for additional safety instructions and compatible parts information.

Chapters

0:00 - Safety Guidelines & Prerequisites
0:22 - Disassembly: Stand & Back Cover
0:30 - Removing Shield, Wireless Module & I/O Cover
0:49 - SSD Removal & Reinstallation

Key Quotes

0:00 "Be sure to read and follow the safety guidelines to protect your computer from potential damage and ensure your personal safety."
0:17 "Before you begin, turn off the computer and disconnect all the attached peripherals."
0:49 "Identify the solid state drive and remove the screw. Lift the drive out of the system."

FAQ

What components need to be removed before accessing the SSD in the Dell Pro 24 AIO?

You must first remove the stand, back cover, system board shield (six screws), wireless module (one screw plus cable disconnection), and I/O cover (two screws) before the 2230 SSD becomes accessible.

Is it safe to replace the SSD myself on the Dell Pro 24 AIO QC24251?

Dell supports DIY replacement on this model, but recommends reading the Owner's Manual safety guidelines, shutting down and unplugging the system, and using proper ESD protection before starting any disassembly.
